粉体气力输送的种类有哪些

文章来源: 作者:罗茨机电 发布时间:2022-01-21 浏览次数:582

返回: 新闻中心

现有的粉体气力输送可分为两类:

The existing pneumatic conveying of powder can be divided into two categories:

(1)稀相气力输送

(1) Dilute phase pneumatic conveying

风速高,物料悬浮液在垂直管内均匀分布,在水平管内飞扬,孔隙率大。物料的输送主要依靠速度较高的空气形成的动能,故又称稀相动压输送

The wind speed is high, the material suspension is evenly distributed in the vertical pipe, flying in the horizontal pipe, and the porosity is large. The transportation of materials mainly depends on the kinetic energy formed by the air with high speed, so it is also called dilute phase dynamic pressure transportation

特点:由于物料流量大,质量流量小,颗粒与管道的碰撞摩擦严重,造成输送系统能耗大、磨损大,生产效率低。适用于输送质量小、粒径小、流动性强的物料

Features: due to large material flow, small mass flow and serious collision and friction between particles and pipeline, the conveying system has high energy consumption, large wear and low production efficiency. It is suitable for conveying materials with small quality, small particle size and strong fluidity

(2)密相气力输送

(2) Dense phase pneumatic conveying

风速在8~15MS之间。物质在管道中不再均匀分布,而是处于稠密状态,但管道没有被物质堵塞,因此仍依靠空气的动能输送,称为密相动压输送

The wind speed is between 8 and 15ms. The material is no longer evenly distributed in the pipeline, but in a dense state, but the pipeline is not blocked by the material, so it still depends on the kinetic energy of air, which is called dense phase dynamic pressure transportation

be9200f367d4dce87f808c2769893798 [更大
宽度 640 更大
高度 480].jpg

这种气体输送装置具有高压输送,高真空抽吸输送和流态化输送。物质与气体的比例变化很大。高压高真空抽吸的料气比约为15~50,流动状态为脉动群流。对于易于运输的粉末,料气比可高达200以上,它以流化

The gas conveying device has high-pressure conveying, high vacuum suction conveying and fluidization conveying. The ratio of substance to gas varies greatly. The feed gas ratio of high pressure and high vacuum suction is about 15 ~ 50, and the flow state is pulsating group flow. For powder that is easy to transport, the material gas ratio can be up to more than 200, which is fluidized

混合粉体输送系统

Mixed powder conveying system

混合输送系统在同一输送系统中既有正压又有负压。利用两种不同系统的优点,可以应用于更复杂的运输。混合系统可以是加压送料或负压吸料。

The mixed conveying system has both positive pressure and negative pressure in the same conveying system. Using the advantages of two different systems, it can be applied to more complex transportation. The mixing system can be pressurized feeding or negative pressure suction.

组合输送系统特点:可完成长距离输送,管道结构及气流变化较为复杂。同时,也容易造成输送系统的磨损,特别是风机。

Characteristics of combined conveying system: it can complete long-distance conveying, and the pipeline structure and air flow change are complex. At the same time, it is also easy to cause wear of the conveying system, especially the fan.

1-吸嘴2-输送管3-分离器4-除尘器5-负压风机

1 - suction nozzle 2 - conveying pipe 3 - separator 4 - dust collector 5 - negative pressure fan

吸风气力输送装置

Suction pneumatic conveying device

特点:负压输送系统是理想的系统,由于输送管道内的压力低于大气压力,管道内不存在气体泄漏的问题,因此更适合输送有毒有害物质。

Features: the negative pressure conveying system is an ideal system. Because the pressure in the conveying pipeline is lower than the atmospheric pressure, there is no problem of gas leakage in the pipeline, so it is more suitable for conveying toxic and harmful substances.
