回转风机风压下降的原因有哪些?

文章来源: 作者:罗茨机电 发布时间:2022-01-04 浏览次数:182

返回: 新闻中心

回转风机三角带检查:回转风机运转一段时间后,三角带会拉伸。此时,松开电机的固定螺栓,移动电机,将三角板拧紧到合适的位置,然后拧紧电机的固定螺栓。注意电机皮带轮和风扇皮带轮的端面在同一平面上。同时,检查两个滑轮的顶部螺丝是否松动。如果松动,请拧紧,每天检查空气过滤器是否脏污。如果脏了,拆下空气过滤器,拧下蝶形螺母,拆下盖子,清洗过滤器。

Inspection of rotary fan V-belt: after the rotary fan operates for a period of time, the V-belt will stretch. At this time, loosen the fixing bolts of the motor, move the motor, tighten the triangular plate to a proper position, and then tighten the fixing bolts of the motor. Note that the end faces of motor pulley and fan pulley are on the same plane. At the same time, check whether the top screws of the two pulleys are loose. If it is loose, tighten it and check whether the air filter is dirty every day. If it is dirty, remove the air filter, unscrew the butterfly nut, remove the cover and clean the filter.


回转风机风压下降的原因及处理法和三角带的检验

Causes and treatment of wind pressure drop of rotary fan and inspection of triangular belt

回转风机三角带检查:

Inspection for triangle belt of rotary fan:

回转风机运转一段时间后,三角带会拉伸。此时,松开电机的固定螺栓,移动电机,将三角板拧紧到合适的位置,然后拧紧电机的固定螺栓。注意电机皮带轮和风扇皮带轮的端面在同一平面上。同时,检查两个滑轮的顶部螺丝是否松动。如果松动,请拧紧,每天检查空气过滤器是否脏污。如果脏了,拆下空气过滤器,拧下蝶形螺母,拆下盖子,清洗过滤器。

After the rotary fan operates for a period of time, the V-belt will stretch. At this time, loosen the fixing bolts of the motor, move the motor, tighten the triangular plate to a proper position, and then tighten the fixing bolts of the motor. Note that the end faces of motor pulley and fan pulley are on the same plane. At the same time, check whether the top screws of the two pulleys are loose. If it is loose, tighten it and check whether the air filter is dirty every day. If it is dirty, remove the air filter, unscrew the butterfly nut, remove the cover and clean the filter.

如何更好地运行、使用和操作回转风机;

How to better operate, use and operate the rotary fan;

1.如果想后期运行效率更高,记得从正规厂家购买这类设备。现在市场上有一些小作坊。虽然三无设备的价格相对较低,但它们的性能和质量并没有得到法的保证

1. If you want to operate more efficiently in the later stage, remember to buy such equipment from regular manufacturers. Now there are some small workshops on the market. Although the price of three noes is relatively low, their performance and quality are not guaranteed by law

2.每种类型的回转风机在安装方法,设备的结构和基本参数上可能存在差异,因此操作前每个人都需要仔细阅读说明书,以确保工作人员掌握了设备的用法,从而正确操作。

2. There may be differences in the installation method, equipment structure and basic parameters of each type of rotary fan. Therefore, everyone needs to carefully read the manual before operation to ensure that the staff master the usage of the equipment and operate correctly.

3.启动顺序和关闭顺序需要按照规定的要求操作,不能随意改变步骤。说明书中会有具体的说明,帮助你更好的操作使用。

3. The startup sequence and shutdown sequence shall be operated according to the specified requirements, and the steps shall not be changed at will. There will be specific instructions in the manual to help you operate and use better.

4.冬天,由于天气寒冷,很多工人都靠近风机的工作环境取暖,这是非常错误的。不能长时间待在这种装备周围,很容易造成皮肤损伤。

4. In winter, due to the cold weather, many workers work close to the fan for heating, which is very wrong. You can't stay around this equipment for a long time, which is easy to cause skin damage.

5.定期清洗回转风机,并采取相应的维护和维修措施,及时发现该类设备的故障或异常现象,并采取措施加以解决,确保设备处于运行状态。

5. Clean the rotary fan regularly, take corresponding maintenance and repair measures, timely find the faults or abnormalities of such equipment, and take measures to solve them to ensure that the equipment is in operation.

回转风机风压下降的原因及处理法:

Causes and treatment of air pressure drop of rotary fan:

1.由于两个叶片之间频繁碰撞,叶轮之间的间隙增加;此时,应调整旋转风扇齿轮的位置,以解决叶瓣碰撞。

1. Due to frequent collision between two blades, the clearance between impellers increases; At this time, the position of the rotating fan gear should be adjusted to solve the lobe collision.

2.混合在气体中的细小杂质摩擦叶瓣,表面,导致叶瓣磨损。此时,应在回转风机的进风口前安装除尘器或气体过滤器;如果叶瓣磨损过度,则有必要修理叶瓣或更换上新的叶瓣

2. The fine impurities mixed in the gas rub the blade surface, resulting in blade wear. At this time, a dust collector or gas filter shall be installed in front of the air inlet of the rotary fan; If the blade is excessively worn, it is necessary to repair the blade or replace it with a new one

3.密封和套管泄漏;此时,应修并填充密封和套管的裂开面。

3. Sealing and casing leakage; At this time, the split surface of the seal and casing shall be repaired and filled.

4.出气管泄漏或破裂;此时,管道应在法兰等地进行修理或填充和紧固

4. Leakage or rupture of air outlet pipe; At this time, the pipeline shall be repaired or filled and fastened in places such as flanges

5.旋转风机转速不足;此时,应调整旋转风机的转速以满足要求。如果传动带松动,需要调整或更换传动带。

5. The rotating fan speed is insufficient; At this time, the rotating speed of the rotating fan shall be adjusted to meet the requirements. If the drive belt is loose, the drive belt needs to be adjusted or replaced.
