不知道大家有没有了解过回转风机厂家呢，知道回转风机碰撞受损的解决办法吗，下面我们就一起来看看吧，望大家在百忙之中一起阅读理解一下吧。回转风机由主机,底座,电机,大小皮带轮,空气室,空气过滤器,滴油嘴等部件组成。

I don't know if you have known about the manufacturer of rotary fan and the solution to the collision damage of rotary fan. Let's have a look. I hope you can read and understand it together in your busy schedule. The rotary fan is composed of main machine, base, motor, pulley, air chamber, air filter, oil dripping nozzle, etc.

甘肃回转风机厂家主机由铸铁浇铸而成,金属环2只，或弹簧8根,主机轴1根,转子1只,滑片4只,偏心缸体1只,泵盖2只组成,其中风机金属环,转子,滑片,泵盖及偏心缸体由耐磨铸件制造,主机轴由45号钢材制造。

The main engine of Gansu rotary fan manufacturer is made of cast iron, including 2 metal rings, 8 springs, 1 main engine shaft, 1 rotor, 4 slides, 1 eccentric cylinder block and 2 pump covers. The metal rings, rotors, slides, pump covers and eccentric cylinder blocks of the fan are made of wear-resistant castings, and the main engine shaft is made of 45 steel.

回转风机4根滑片嵌入在等分的转子内,回转风机轴紧固在转子中心,轴的两端装有轴承与前后泵盖连接安装在偏心的缸体上,此时转子与4根嵌入在转子内的滑片与缸体内壁形成4个容积不等的空间,在回转风机运行过程中,金属环或弹簧推动滑片沿缸体内壁匀速运动,回转风机缸体由吸入口,吸气口导气槽,排气口,排气口导气槽组成。回转风机的工作过程由:吸气行程,压缩行程,排出行程三部分组成。回转风机旋转时，使转子槽内的4根滑片产生往复运动，将空气吸进、压缩、排出，构成风机。

Four slides of the rotary fan are embedded in the equally divided rotor. The shaft of the rotary fan is fixed in the center of the rotor. Bearings are installed at both ends of the shaft, which are connected with the front and rear pump covers and installed on the eccentric cylinder block. At this time, the rotor, the four slides embedded in the rotor and the inner wall of the cylinder block form four spaces with different volumes. During the operation of the rotary fan, the metal ring or spring pushes the slides to move uniformly along the inner wall of the cylinder, The cylinder body of rotary fan is composed of suction port, suction port air guide groove, exhaust port and exhaust port air guide groove. The working process of rotary fan consists of three parts: suction stroke, compression stroke and discharge stroke. When the rotary fan rotates, the four slides in the rotor slot produce reciprocating motion, and the air is sucked in, compressed and discharged to form the fan.

回转风机受碰撞后，可能引起风机转子靠偏，风机运转不灵，可松开螺栓，轻敲见机后盖，同时拉动风机皮带直到能拉动风机皮带、无轻重感为止。回转风机受碰撞后，可能引起风机转子靠偏，风机运转不灵。回转风机如发生碰撞事故，首先用手拉一下风机皮带，试一下风机是否能正常转动，如风机能正常转动，无轻重感，则风机无故障现象。如风机不能拉动，或能拉动但有轻重感，则说明风机转子靠偏，此时可松开后盖螺栓，用木锤轻轻敲打风机后盖，同时拉动风机皮带，直到能拉动风机皮带、无轻重感为止，再拧紧后盖即可。

After the rotary fan is collided, the rotor of the fan may deviate and the fan may not work properly. Loosen the bolts, tap the back cover of the fan, and pull the fan belt until the fan belt can be pulled and there is no sense of weight. After the rotary fan is collided, the rotor of the fan may be deviated and the fan may not work properly. In case of collision accident of rotary fan, first pull the fan belt by hand to test whether the fan can rotate normally. If the fan can rotate normally and has no sense of weight, the fan has no fault. If the fan can't be pulled, or can be pulled but has light and heavy feeling, it means that the rotor of the fan is leaning. At this time, loosen the bolts of the back cover, gently tap the back cover of the fan with a wooden hammer, and pull the fan belt at the same time until the fan belt can be pulled without light and heavy feeling, and then tighten the back cover.

感谢您的阅读，希望以上内容能对您有所帮助，如您想了解更多精彩内容请点击我们的官网：甘肃回转风机厂家。

Thank you for reading, hope the above content can help you, if you want to know more wonderful content, please click our official website: Gansu rotary fan manufacturer.
